Description

GENERAL FEATURES

Units
Dimensions W x H x D 150 x 205 x 70 mm
Display Case with graphical display and configuration thumbwheel
Power supply Lithium battery
Autonomy Typical battery life : 4 years
Protection rating IP20
Operating temperature -20°C to +50°C
Technical characteristics
Inputs / Outputs 6 Di Inputs :
• 2 usable for metering
2 AI Inputs :
• for 4-20 mA sensors
• sensors powered by HF-BOX 2 (12 V)
Radio License-free
869 MHz, 0,5 W
Range : up to 10 km (sites in line of sight)
Radio Module can be placed up to 50 m away
